FEMCO BMC-Series is a full line of Horizontal Boring Mills with 10 distinctive models. Featuring full 4th Rotary Axis tables; heavy table load capacities; extended reach of W-Axes. Each model provides specific capabilities for machining of large, complex parts.

1
Yes
None
1
1000000
Name...
/bmt-123/
Thumbnail

Categories:

BMC-100HT
BMC-100HT Image

BMC-100HT

T-Type Traveling Column High Speed CNC Horizontal Boring & Milling Machine ideal for machining large molds as well as large aluminum parts. With an astounding table load capacity of 44,000 Lbs., and a 50 Taper Spindle, the BMC-100HT can handle the largest of steel  molds.

  • Spindle Speed 8,000 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B-Axis Rotary Table (44,000 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 118.1” x 80.7” x 59.05”
BMC-110FR1 with Automatic Pallet Changer
BMC-110FR1 with Automatic Pallet Changer Image

BMC-110FR1 with Automatic Pallet Changer

The Automatic Pallet Changer (APC) is an integral part of this compact CNC Horizontal Boring & Milling Machine with built-in Programmable U-axis Facing and Profile Turning Head. The U-Axis allows for intricate contouring of inside and outer diameters and is ideal for machining of complex valves pumps, gearbox housings, as well as tube and joint end preparation. The BMC-110FR1 comes standard with a 50 Taper, 35 HP Geared Head Spindle; Full B-Axis Rotary Table; linear scales on X, Y & Z-Axes; chip conveyor; a Fanuc CNC control, and for added capability, also incorporates a W-Axis Bar for deep boring.

  • Spindle Speed 2,500 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B Axis Rotary Table (6,000 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 55.12” x 54.72” x 43.31”
  • Travel U-Axis: 9.055”
  • Travel W-Axis: 5.11”
BMC-110FT2 with Facing Head
BMC-110FT2 with Facing Head Image

BMC-110FT2 with Facing Head

T-Type Traveling Column CNC Horizontal Boring & Milling Machine with built-in Programmable U-axis Facing and Profile Turning Head. The U-Axis allows for intricate contouring of inside and outer diameters and is ideal for machining of complex valves, pumps, gearbox housings, as well as tube and joint end preparation. The BMC-110FT2 comes standard with a 50 Taper, 35 HP Geared Head Spindle; Full B-Axis Rotary Table; linear scales on X, Y & Z-Axes; chip conveyor; a Fanuc CNC control, and for added capability, also incorporates a W-Axis Bar for deep boring.

  • Spindle Speed 2,500 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B-Axis Rotary Table (17,600 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 78.74”x 80.7”x 59.05”
  • Travel U-Axis: 9.055”
  • Travel W-Axis: 9.8”
BMC-110FT3 with Facing Head
BMC-110FT3 with Facing Head Image

BMC-110FT3 with Facing Head

T-Type Traveling Column CNC Horizontal Boring & Milling Machine with built-in Programmable U-axis Facing and Profile Turning Head as well as an extended X-Axis travel of 118.1”. The U-Axis allows for intricate contouring of inside and outer diameters and is ideal for machining of complex valves, pumps, gearbox housings, as well as tube and joint end preparation. The BMC-110FT3 comes standard with a 50 Taper, 35 HP Geared Head Spindle; Full B-Axis Rotary Table; linear scales on X, Y & Z-Axes; chip conveyor; a Fanuc CNC control, and for added capability, also incorporates a W-Axis Bar for deep boring.

  • Spindle Speed 2,500 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B-Axis Rotary Table (17,600 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 118.1”x 80.7”x 59.05”
  • Travel U-Axis: 9.055”
  • Travel W-Axis: 9.8”
BMC-110FT4 with Facing Head
BMC-110FT4 with Facing Head Image

BMC-110FT4 with Facing Head

T-Type Traveling Column CNC Horizontal Boring & Milling Machine with built-in Programmable U-axis Facing and Profile Turning Head as well as an extended X-Axis travel of 157.5”. The U-Axis allows for intricate contouring of inside and outer diameters and is ideal for machining of complex valves, pumps, gearbox housings, as well as tube and joint end preparation. The BMC-110FT4 comes standard with a 50 Taper, 35 HP Geared Head Spindle; Full B-Axis Rotary Table; linear scales on X, Y & Z-Axes; chip conveyor; a Fanuc CNC control, and for added capability, also incorporates a W-Axis Bar for deep boring.

  • Spindle Speed 2,500 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B-Axis Rotary Table (17,600 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 157.5”x 80.7”x 59.05”
  • Travel U-Axis: 9.055”
  • Travel W-Axis: 9.8”
BMC-110R1
BMC-110R1 Image

BMC-110R1

CNC Horizontal Boring & Milling Machine with the smallest footprint of our BMC Series comes standard with a 50 Taper, 35 HP Geared Head Spindle, Full B-Axis Rotary Table, linear scales on X, Y & Z, chip conveyor and a Fanuc CNC control. The BMC-110R1 W-Axis Bar stroke is 19.69” and has a robust diameter of 4.33”

  • Spindle Speed 2,500 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B-Axis Rotary Table (8,819 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 55.12” x 54.72” x 43.31”
  • Travel W-Axis: 19.69”
BMC-110R1 with Automatic Pallet Changer
BMC-110R1 with Automatic Pallet Changer Image

BMC-110R1 with Automatic Pallet Changer

The Automatic Pallet Changer (APC) is an integral part of this compact CNC Horizontal Boring & Milling Machine, which comes standard with a 50 Taper, 35 HP Geared Head Spindle, Full B Axis Rotary Table, linear scales on X, Y & Z, chip conveyor and a Fanuc CNC control. The BMC-110R1 W-Axis Bar stroke is 19.69” and has a robust diameter of 4.33”

  • Spindle Speed 2,500 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B-Axis Rotary Table (6,000 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 55.12” x 54.72” x 43.31”
  • Travel W-Axis: 19.69”
BMC-110R2
BMC-110R2 Image

BMC-110R2

CNC Horizontal Boring & Milling Machine comes standard with a 50 Taper, 35 HP Geared Head Spindle, Full B Axis Rotary Table, linear scales on X, Y & Z, chip conveyor and a Fanuc CNC control. The BMC-110R2 W-Axis Bar stroke is 19.69” and has a robust diameter of 4.33”.

  • Spindle Speed 2,500 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B-Axis Rotary Table (13,889 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 78.74” x 70.87” x 64.96”
  • Travel W-Axis: 19.69”
BMC-110R3
BMC-110R3 Image

BMC-110R3

CNC Horizontal Boring & Milling Machine comes standard with a 50 Taper, 35 HP Geared Head Spindle, Full B Axis Rotary Table, linear scales on X, Y & Z, chip conveyor and a Fanuc CNC control. The BMC-110R3 has an extended X-Axis travel of 118.1” and incorporates a W-Axis Bar stroke of 19.69” with a robust diameter of 4.33”.

  • Spindle Speed 2,500 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B-Axis Rotary Table (13,889 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 118.1” x 70.87” x 64.96”
  • Travel W-Axis: 19.69”
BMC-110T2
BMC-110T2 Image

BMC-110T2

Heavy duty T-Type Traveling Column CNC Horizontal Boring & Milling Machine comes standard with a 50 Taper, 35 HP Geared Head Spindle; Full B-Axis Rotary Table; linear scales on X, Y & Z-Axes; chip conveyor; a Fanuc CNC control. The BMC-110T2 W-Axis Bar stroke is 19.69” and has a robust diameter of 4.33”.Spindle Speed

  • 2,500 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B-Axis Rotary Table (17,600 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 78.74”x 80.7”x 59.05”
  • Travel W-Axis: 19.69”
BMC-110T3
BMC-110T3 Image

BMC-110T3

Heavy duty T-Type Traveling Column CNC Horizontal Boring & Milling Machine comes standard with a 50 Taper, 35 HP Geared Head Spindle; Full B-Axis Rotary Table; linear scales on X, Y & Z-Axes; chip conveyor; a Fanuc CNC control. The BMC-110T3 has an extended X-Axis travel of 118.1” and incorporates a W-Axis Bar stroke of 19.69” with a robust diameter of 4.33”.

  • 2,500 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B-Axis Rotary Table (17,600 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 118.1”x 80.7”x 59.05”
  • Travel W-Axis: 19.69”
BMC-110T4
BMC-110T4 Image

BMC-110T4

Heavy duty T-Type Traveling Column CNC Horizontal Boring & Milling Machine comes standard with a 50 Taper, 35 HP Geared Head Spindle; Full B-Axis Rotary Table; linear scales on X, Y & Z-Axes; chip conveyor; a Fanuc CNC control. The BMC-110T4 has an extended X-Axis travel of 157.5” and incorporates a W-Axis Bar stroke of 19.69” with a robust diameter of 4.33”.

  • 2,500 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B-Axis Rotary Table (17,600 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 157.5”x 80.7”x 59.05”
  • Travel W-Axis: 19.69”
BMC-135R
BMC-135R Image

BMC-135R

Heavy duty, large capacity CNC Horizontal Boring & Milling Machine comes standard with a 50 Taper, 35 HP Geared Head Spindle, Full B Axis Rotary Table, linear scales on X, Y & Z, chip conveyor and a Fanuc CNC control. The BMC-135R has an extended X-Axis travel of 94.49” and incorporates a long W-Axis Bar stroke of 35.43” with a very robust diameter of 5.31”.

  • Spindle Speed 1,500 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B-Axis Rotary Table (22,046 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 94.49” x 82.68” x 59.06”
  • Travel W-Axis: 35.43”
BMC-135T
BMC-135T Image

BMC-135T

Heavy duty, large capacity T-Type Traveling Column CNC Horizontal Boring & Milling Machine comes standard with a 50 Taper, 35 HP Geared Head Spindle, Full B Axis Rotary Table, linear scales on X, Y & Z, chip conveyor and a Fanuc CNC control. The BMC-135 has an extended X-Axis travel of 118.11” and incorporates a long W-Axis Bar stroke of 35.43” with a very robust diameter of 5.31”.

  • Spindle Speed 1,500 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B-Axis Rotary Table (33,000 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 118.11” x 82.68” x 78.74”
  • Travel W-Axis: 35.43”
BMC-135TN
BMC-135TN Image

BMC-135TN

Heavy duty, large capacity T-Type Traveling Column CNC Horizontal Boring & Milling Machine comes standard with a 50 Taper, 35 HP Geared Head Spindle, Full B Axis Rotary Table, linear scales on X, Y & Z, chip conveyor and a Fanuc CNC control. The BMC-135TN has extended travels of 118.11” in the X-Axis and 98.42” in the Y-Axis as well as the long W-Axis Bar stroke of 35.43” with the very robust diameter of 5.31”.

  • Spindle Speed 1,500 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B-Axis Rotary Table (33,000 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 118.11” x 98.42” x 59.05”
  • Travel W-Axis: 35.43”
BMC-250T
BMC-250T Image

BMC-250T

Heavy duty T-Type Traveling Column CNC Horizontal Boring & Milling Machine comes standard with a 50 Taper, 35 HP Geared Head Spindle; Full B-Axis Rotary Table; linear scales on X, Y & Z-Axes; chip conveyor; a Fanuc CNC control. The BMC-110T2 has a unique W-Axis Ram with a stroke of 27.56” and a large diameter of 9.54”.

  • Spindle Speed 6,000 RPM (CT-50 Taper – 30/35 HP)
  • Through Spindle Coolant
  • 60 Tool ATC
  • Full B-Axis Rotary Table (17,600 Lbs. Load Capacity)
  • Travels X, Y & Z-Axes: 78.74”x 80.7”x 59.05”
  • Travel W-Axis Ram: 27.56”
